Manual setup operation
After applying supply voltage (see chapter 4.2), the position indicator will
be on the uppermost level of the menu structure (default/delivery state).
• Pressing the key enables or disables the incremental measurement
function.
• Pressing the key starts calibration (see User manual).
• Pressing the key starts the parameter / programming mode (see
User manual).
LED displays
In the basic state (factory setting), the LED display has the following
meaning.
Color State Description
green on Actual position value is within the programmed
position window.
o Actual position value is outside the programmed
position window.
red on Actual position value is outside the programmed
position window.
o Actual position value is within the programmed
position window.
Konfiguration
(only CAN + RS485/SIKONETZ3,4)
The required parameters are set in the configuration mode. On the 1st line
of the display, the parameter will be shown and on the 2nd line the res-
pective value will be displayed.
Press key for changing actual value and / or the blinking digit when
entering a multi-digit value.
The key serves for switching to the next digit in case of multi-digit
numbers.
By pressing the key, the set value is acknowledged and saved non-
volatilely. If no key is pressed, the configuration mode will be exited after
~30s without saving the latest value displayed, i. e. the original value will
be maintained.
