AP10
Installation English
AP10 · Date 10.01.2020 · Art. No. 86832 · Mod. status 6/20
27
Loss of type of connection/shielding
If the torque of the mating connector is too low this will result in loss of
type of protection and/or shielding.
` Tighten the mating connector using the torque-limiting wrench of the
relevant connector vendor. Pay attention to the tightening torque
specified by the manufacturer.
` Using a torque wrench tighten the mating connector (see chapter 8.1,
8.2 and 8.3). Manufacturer's recommendation of a suitable torque can
be obtained on request. Tightening torque: 0.4 Nm
If the use of the torque-limiting wrench is not possible due to the moun-
ting situation, execute electrical installation before mechanical installa-
tion.
4.1 Mechanical mounting
Destruction of main bearings
Improper installation (e. g. tension on the driving shaft) causes additio-
nal heat development and destruction of the position indicator in the long
term.
` Ensure a low shaft and angle oset between shaft and accommoda-
tion bore by applying appropriate manufacturing methods (see Fig. 1
+ Tab. 1).
Destruction of the position indicator
Heavy dirt load results in reduced service life of the main bearing.
` Apply protective measures (e. g. V-ring) in order to reduce the dirt
load.
Position indicator failure
` When mounting pay attention to the IP type of protection (see chap-
ter 9).
` Do not open the position indicator yourself (exception: see chapter 6).
` Avoid impact on the device.
` Do not modify the device in any way.
Preparing mounting (Fig. 1, Fig. 2, Fig. 3):
1. Make the bore ød for torque support
1
at distance L1 to the drive
shaft
2
.
2. Pay attention to the diameter øD of the drive shaft
3
.
CAUTION
NOTICE
CAUTION
CAUTION
CAUTION
