AP10

Installation English

AP10 · Date 10.01.2020 · Art. No. 86832 · Mod. status 6/20

Unforeseen actions of the position indicator or other devices

The position indicator is protected against EMC irradiation and emission

(electromagnetic compatibility). Excessive external EMC inﬂuence may

trigger unforeseen position indicator actions (including destruction of the

position indicator; loss of position value).

` Perform wiring work in accordance with the EMC measures IEC 61326-1

and chapter 4.2.

` Check the correct execution of the EMC measures.

Danger of ﬁre

In order to avoid consequential damage in case of device defects the fol-

lowing fusing is recommended.

` The nominal current rating of a delay fuse must be adjusted to the

number of devices in the system (see chapter 9).

Basically, all connections are protected against external interference.

Choose a place of operation that excludes inductive or capacitive inter-

ference inﬂuences on the position indicator. When mounting the system

keep a maximum possible distance from lines loaded with interference. If

necessary, provide additional installations including screening shields or

metallized housings. Contactor coils must be linked with spark suppres-

sion.

4.3 Connection concept (RS485, CANopen)

When operated together, multiple position indicators must be connected

to a common GND potential. For this purpose, the GND signal must always

be carried along in the bus wiring.

Potentially live contacts must be protected against touch. Therefore, take

care that the position indicator is connected via the "Bus On" connec-

tion (see Fig. 6). This ensures protection of the live contacts on "Bus O"

by means of the jack (for the IP type of protection, please refer to chap-

ter 4.1).

Connection diagram

Faulty or missing termination

Faulty or missing termination or level speciﬁcation results in communica-

tion errors and can destroy the displays electronic system.

` Make sure that termination is correct and test it.

WARNING

NOTICE

CAUTION
