AP10
Battery change English
AP10 · Date 10.01.2020 · Art. No. 86832 · Mod. status 6/20
37
6.1 Battery, function and service life
• SIKO battery unit order number: art. no. "ZB1027".
The battery enables capturing of the absolute position value as well as the
detection of currentless shaft adjustments. The average battery service
life is approximately 5 years depending on the ambient conditions and
duration of position indicator supply voltage application. The battery can
be changed at SIKO distribution partners, in the SIKO parent factory or by
yourself.
6.2 Operating states
Battery symbol blinking: Battery nearly empty
In standard operation, ~3 months are left until the battery will be comple-
tely discharged.
Battery symbol glowing: Replace battery
6.3 Changing the battery unit
Position indicator failure
Improper installation results in loss of type of protection.
` Evenly tighten the screws
1
until the battery unit
2
is completely
aligned with the LCD housing
4
.
` Check the correct position of the O-ring
3
.
Preparation:
1. Connect position indicator to supply voltage.
2. Place the replacement battery unit ready (see chapter 6.1).
3. Place a Phillips screwdriver ready (e. g. PH 0x60).
Deinstallation (see Fig. 11):
1. The battery compartment is situated on the left side of the device
(connections below).
2. Unscrew 3 fastening screws
1
.
3. Take out the battery unit
2
(refer to chapter 7 for disposal of the old
battery).
Installation (see Fig. 11):
1. Insert new battery unit
2
. Take care that it can be inserted easily.
2. Check the correct position of the O ring
3
. When mounting the bat-
tery unit,
2
the O-ring must lie all round the battery housing.
CAUTION
