REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5411
7-9
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
(d)
Q905 8-729-048-53 TRANSISTOR 2SJ569LS-CB11
Q906 8-729-044-21 TRANSISTOR 2SK2655-01R-F165
Q907 8-729-033-26 TRANSISTOR DTA114GKAT146
Q908 8-729-033-25 TRANSISTOR DTC114GKA
<RESISTOR>
R501 1-215-884-11 METAL OXIDE 47 5% 2W F
R502 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R503 1-216-049-91 RES,CHIP 1K 5% 1/10W
R504 1-216-049-91 RES,CHIP 1K 5% 1/10W
R505 1-216-049-91 RES,CHIP 1K 5% 1/10W
R506 1-216-049-91 RES,CHIP 1K 5% 1/10W
R507 1-216-097-91 RES,CHIP 100K 5% 1/10W
R508 1-247-815-91 CARBON 220 5% 1/4W
R509 1-216-049-91 RES,CHIP 1K 5% 1/10W
R510 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R511 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R512 1-215-453-00 METAL 22K 1% 1/4W
R513 1-216-049-91 RES,CHIP 1K 5% 1/10W
R514 1-216-097-91 RES,CHIP 100K 5% 1/10W
R515 1-216-049-91 RES,CHIP 1K 5% 1/10W
R516 1-216-049-91 RES,CHIP 1K 5% 1/10W
R517 1-216-687-11 METAL CHIP 33K 0.50%1/10W
R518 1-216-691-11 METAL CHIP 47K 0.50%1/10W
R519 1-216-081-00 RES,CHIP 22K 5% 1/10W
R520 1-247-791-91 CARBON 22 5% 1/4W
R521 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R522 1-249-437-11 CARBON 47K 5% 1/4W
R523 1-216-033-00 RES,CHIP 220 5% 1/10W
R524 1-216-049-91 RES,CHIP 1K 5% 1/10W
R525 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R526 1-216-097-91 RES,CHIP 100K 5% 1/10W
R527 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R528 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R529 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R530 1-216-049-91 RES,CHIP 1K 5% 1/10W
R531 1-216-097-91 RES,CHIP 100K 5% 1/10W
R532 1-215-860-11 METAL OXIDE 33 5% 1W F
R533 1-211-796-11 FUSIBLE 1 5% 1/2W F
R534 1-216-689-11 METAL CHIP 39K 0.50%1/10W
R535 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R536 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R537 1-249-437-11 CARBON 47K 5% 1/4W
R538 1-216-049-91 RES,CHIP 1K 5% 1/10W
R539 1-216-097-91 RES,CHIP 100K 5% 1/10W
R540 1-215-909-11 METAL OXIDE 47 5% 3W F
R541 1-216-295-91 SHORT 0
R542 1-249-437-11 CARBON 47K 5% 1/4W
R543 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R544 1-216-049-91 RES,CHIP 1K 5% 1/10W
R545 1-216-097-91 RES,CHIP 100K 5% 1/10W
R546 1-216-381-11 METAL OXIDE 0.22 5% 3W F
R547 1-219-726-11 METAL 2.2 5% 10W
R548 1-249-437-11 CARBON 47K 5% 1/4W
R549 1-260-288-11 CARBON 0.47 5% 1/2W
R550 1-260-288-11 CARBON 0.47 5% 1/2W
R551 1-216-049-91 RES,CHIP 1K 5% 1/10W
R552 1-216-097-91 RES,CHIP 100K 5% 1/10W
R553 1-247-815-91 CARBON 220 5% 1/4W
R554 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R555 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R556 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R557 1-216-423-11 METAL OXIDE 27 5% 1W F
R558 1-249-437-11 CARBON 47K 5% 1/4W
R559 1-216-073-00 RES,CHIP 10K 5% 1/10W
R560 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R561 1-215-443-00 METAL 8.2K 1% 1/4W
R562 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R563 1-216-049-91 RES,CHIP 1K 5% 1/10W
R564 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R565 1-216-097-91 RES,CHIP 100K 5% 1/10W
R566 1-216-687-11 METAL CHIP 33K 0.50%1/10W
R567 1-214-840-00 METAL 100 1% 1/2W
R568 1-216-665-11 METAL CHIP 3.9K 0.50%1/10W
R569 1-216-691-11 METAL CHIP 47K 0.50%1/10W
R570 1-260-332-51 CARBON 2.2K 5% 1/2W
R571 1-249-425-11 CARBON 4.7K 5% 1/4W
R572 1-216-385-11 METAL OXIDE 0.47 5% 3W F
R573 1-249-437-11 CARBON 47K 5% 1/4W
R574 1-216-097-91 RES,CHIP 100K 5% 1/10W
R575 1-216-672-11 METAL CHIP 7.5K 0.50%1/10W
R576 1-215-869-11 METAL OXIDE 1K 5% 1W F
R577 1-260-310-71 CARBON 33 5% 1/2W
R578 1-216-049-91 RES,CHIP 1K 5% 1/10W
R579 1-216-049-91 RES,CHIP 1K 5% 1/10W
R580 1-214-840-00 METAL 100 1% 1/2W
R581 1-260-316-51 CARBON 100 5% 1/2W
R582 1-214-840-00 METAL 100 1% 1/2W
R583 1-249-437-11 CARBON 47K 5% 1/4W
R584 1-249-437-11 CARBON 47K 5% 1/4W
R585 1-216-073-00 RES,CHIP 10K 5% 1/10W
R586 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R587 1-215-886-11 METAL OXIDE 100 5% 2W F
R588 1-260-085-11 CARBON 68 5% 1/2W
R589 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R590 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R591 1-247-807-31 CARBON 100 5% 1/4W
R593 1-216-073-00 RES,CHIP 10K 5% 1/10W
R594 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R595 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R597 1-216-073-00 RES,CHIP 10K 5% 1/10W
R598 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R599 1-216-657-11 METAL CHIP 1.8K 0.50%1/10W
R701 1-216-049-91 RES,CHIP 1K 5% 1/10W
R702 1-249-393-11 CARBON 10 5% 1/4W F
R703 1-215-459-00 METAL 39K 1% 1/4W
R704 1-216-655-11 METAL CHIP 1.5K 0.50%1/10W
R705 1-249-413-11 CARBON 470 5% 1/4W F
R706 1-249-389-11 CARBON 4.7 5% 1/4W F
R707 1-249-389-11 CARBON 4.7 5% 1/4W F
