Silicon Graphics GDM-5411 User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5411
7-10
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
(d)(h)
R708 1-215-881-11 METAL OXIDE 15 5% 2W F
R709 1-216-049-91 RES,CHIP 1K 5% 1/10W
R710 1-216-073-00 RES,CHIP 10K 5% 1/10W
R711 1-216-049-91 RES,CHIP 1K 5% 1/10W
R713 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R714 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R715 1-249-389-11 CARBON 4.7 5% 1/4W F
R716 1-216-689-11 RES,CHIP 39K 5% 1/10W
R717 1-216-073-00 RES,CHIP 10K 5% 1/10W
R718 1-216-681-11 METAL CHIP 18K 0.50%1/10W
R719 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R720 1-216-073-00 RES,CHIP 10K 5% 1/10W
R721 1-216-073-00 RES,CHIP 10K 5% 1/10W
R722 1-260-292-11 CARBON 1 5% 1/2W
R723 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R724 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R725 1-214-798-21 METAL 1.8 1% 1/2W
R726 1-214-798-21 METAL 1.8 1% 1/2W
R727 1-249-381-11 CARBON 1 5% 1/4W F
R728 1-215-865-11 METAL OXIDE 220 5% 1W F
R729 1-260-292-11 CARBON 1 5% 1/2W
R730 1-216-073-00 RES,CHIP 10K 5% 1/10W
R731 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R732 1-219-510-11 CARBON 470K 5% 1/2W
R901 1-216-097-91 RES,CHIP 100K 5% 1/10W
R902 1-216-117-00 RES,CHIP 680K 5% 1/10W
R903 1-216-089-91 RES,CHIP 47K 5% 1/10W
R904 1-216-033-00 RES,CHIP 220 5% 1/10W
R906 1-216-033-00 RES,CHIP 220 5% 1/10W
R907 1-216-081-00 RES,CHIP 22K 5% 1/10W
R908 1-216-399-00 METAL OXIDE 6.8 5% 3W F
R911 1-216-041-00 RES,CHIP 470 5% 1/10W
R912 1-216-049-91 RES,CHIP 1K 5% 1/10W
R914 1-247-791-91 CARBON 22 5% 1/4W
R915 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R916 1-249-397-11 CARBON 22 5% 1/4W F
R917 1-211-824-71 FUSIBLE 220 5% 1/2W F
R918 1-219-727-11 METAL 68 5% 10W
R919 1-219-748-11 CARBON 4.7K 5% 1/2W
R920 1-216-089-91 RES,CHIP 47K 5% 1/10W
R921 1-249-429-11 CARBON 10K 5% 1/4W
R922 1-249-389-11 CARBON 4.7 5% 1/4W F
R923 1-218-762-11 METAL CHIP 270K 0.50%1/10W
R924 1-216-073-00 RES,CHIP 10K 5% 1/10W
R925 1-220-825-11 CARBON 330K 5% 1/2W
R926 1-219-746-11 CARBON 1K 5% 1/2W
R927 1-219-746-11 CARBON 1K 5% 1/2W
R928 1-216-668-11 METAL CHIP 5.1K 0.50%1/10W
R929 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R930 1-216-653-11 METAL CHIP 1.2K 0.50%1/10W
R931 1-216-653-11 METAL CHIP 1.2K 0.50%1/10W
R932 1-216-049-91 RES,CHIP 1K 5% 1/10W
R933 1-216-687-11 METAL CHIP 33K 0.50%1/10W
R934 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R935 1-216-089-91 RES,CHIP 47K 5% 1/10W
R937 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R939 1-216-049-91 RES,CHIP 1K 5% 1/10W
R940 1-216-073-00 RES,CHIP 10K 5% 1/10W
R941 1-216-025-91 RES,CHIP 100 5% 1/10W
R943 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R945 1-216-025-91 RES,CHIP 100 5% 1/10W
R1501 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1502 1-216-033-00 RES,CHIP 220 5% 1/10W
R1503 1-216-682-11 METAL CHIP 20K 0.50%1/10W
R1504 1-216-665-11 METAL CHIP 3.9K 0.50%1/10W
R1505 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R1506 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1507 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1510 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1515 1-215-909-11 METAL OXIDE 47 5% 3W F
R1517 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1518 1-216-025-91 RES,CHIP 100 5% 1/10W
<VARIABLE RESISTOR>
[ RV901 ¡ 1-241-767-21RES, ADJ, CERMET 100K (HVADJ)
<RELAY>
RY501 1-755-198-11 RELAY
<SPARK GAP>
SG901 1-517-499-21 GAP, SPARK
SG902 1-519-422-11 GAP, SPARK
SG903 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 1-435-070-11 TRANSFORMER, HORIZONTAL DRIVE
T502 1-429-301-11 TRANSFORMER, FERRITE (HCT)
T503 1-431-413-21 TRANSFORMER, FERRITE (HST)
T505 1-419-127-11 COIL, HORIZONTAL LINEARITY
T701 1-431-414-11 TRANSFORMER, FERRITE (DFT)
T901 1-416-402-11 INDUCTOR 500µH
T902 ¡ X-4560-175-1 TRANSFORMER ASSY, FLYBACK
(NX-4502//J1D4)
<THERMISTOR>
TH501 1-807-796-11 THERMISTOR
TH502 1-807-796-11 THERMISTOR
*******************************************************************************
* A-1372-632-AH BOARD, COMPLETE
****************************
<CAPACITOR>
C810 1-126-791-11 ELECT 10µF 20% 16V
The components identified by [ in this
manual have been carefully factory-
selected for eachset in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
