REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5411
7-11
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
(h)(j)(n)
C814 1-126-786-11 ELECT 47µF 20% 16V
<CONNECTOR>
CN801*1-564-526-11 PLUG, CONNECTOR 11P
<DIODE>
D801 8-719-064-11 DIODE SPR-325MVW
<TRANSISTOR>
Q801 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q803 8-729-029-40 TRANSISTOR DTA124ESA
Q804 8-729-029-40 TRANSISTOR DTA124ESA
<RESISTOR>
R801 1-249-413-11 CARBON 470 5% 1/4W
R802 1-247-807-31 CARBON 100 5% 1/4W
R803 1-247-807-31 CARBON 100 5% 1/4W
R804 1-247-815-91 CARBON 220 5% 1/4W
R805 1-247-815-91 CARBON 220 5% 1/4W
R806 1-249-413-11 CARBON 470 5% 1/4W
R807 1-247-831-91 CARBON 1K 5% 1/4W
R811 1-249-429-11 CARBON 10K 5% 1/4W
R812 1-249-429-11 CARBON 10K 5% 1/4W
R813 1-247-863-91 CARBON 22K 5% 1/4W
R814 1-249-441-11 CARBON 100K 5% 1/4W
R815 1-249-429-11 CARBON 10K 5% 1/4W
R821 1-249-407-11 CARBON 150 5% 1/4W
R822 1-249-413-11 CARBON 470 5% 1/4W
R823 1-247-831-91 CARBON 1K 5% 1/4W
R824 1-249-419-11 CARBON 1.5K 5% 1/4W
<SWITCH>
S800 1-571-588-11 SWITCH, SLIDE (INPUT SELECT)
S801 1-692-431-21 SWITCH, TACTILE (RESET)
S802 1-692-431-21 SWITCH, TACTILE (ASC)
S803 1-692-431-21 SWITCH, TACTILE (V-)
S804 1-692-431-21 SWITCH, TACTILE (V+)
S805 1-692-431-21 SWITCH, TACTILE (MENU)
S806 1-692-431-21 SWITCH, TACTILE (H-)
S807 1-692-431-21 SWITCH, TACTILE (H+)
<THERMISTOR>
TH801 1-807-796-11 THERMISTOR
*******************************************************************************
* A-1388-250-BJ BOARD, COMPLETE
***************************
<CONNECTOR>
CN891*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
<SWITCH>
S891 ¡ 1-571-433-31 SWITCH, PUSH (AC POWER)
*******************************************************************************
* A-1394-980-A N BOARD, COMPLETE
****************************
<CAPACITOR>
C001 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C002 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C003 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C005 1-163-255-91 CERAMIC CHIP 150pF 5% 50V
C006 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C007 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C008 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C009 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C010 1-126-967-11 ELECT 47µF 20% 50V
C011 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C012 1-126-967-11 ELECT 47µF 20% 50V
C013 1-126-965-11 ELECT 22µF 20% 50V
C014 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C015 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C016 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C017 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C018 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C019 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C020 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C021 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C022 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C023 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C024 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C025 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C026 1-104-665-11 ELECT 100µF 20% 25V
C027 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C028 1-163-220-11 CERAMIC CHIP 3pF 0.25pF 50V
C029 1-163-241-11 CERAMIC CHIP 39pF 5% 50V
C031 1-126-964-11 ELECT 10µF 20% 50V
C033 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C036 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C037 1-126-964-11 ELECT 10µF 20% 50V
C038 1-126-964-11 ELECT 10µF 20% 50V
C039 1-126-964-11 ELECT 10µF 20% 50V
C040 1-126-964-11 ELECT 10µF 20% 50V
C041 1-126-964-11 ELECT 10µF 20% 50V
