Silicon Graphics GDM-5411 User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5411
7-12
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
(n)
C042 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C043 1-126-965-11 ELECT 22µF 20% 50V
C044 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C045 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C046 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C047 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C048 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C049 1-126-964-11 ELECT 10µF 20% 50V
C050 1-126-964-11 ELECT 10µF 20% 50V
C051 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C052 1-126-933-11 ELECT 100µF 20% 16V
C053 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C054 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C055 1-104-664-11 ELECT 47µF 20% 25V
C056 1-126-965-11 ELECT 22µF 20% 50V
C057 1-126-964-11 ELECT 10µF 20% 50V
C058 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C059 1-126-964-11 ELECT 10µF 20% 50V
C061 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C062 1-126-925-11 ELECT 470µF 20% 10V
C063 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C064 1-115-419-11 CERAMIC CHIP 3300pF 5% 25V
C065 1-126-960-11 ELECT 1µF 20% 50V
C066 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C067 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C068 1-136-169-00 FILM 0.22µF 5% 50V
C069 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C070 1-126-767-11 ELECT 1000µF 20% 16V
C071 1-163-007-11 CERAMIC CHIP 680pF 10% 50V
C072 1-126-942-61 ELECT 1000µF 20% 25V
C073 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C074 1-163-137-00 CERAMIC CHIP 680pF 5% 50V
C075 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C077 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C078 1-136-169-00 FILM 0.22µF 5% 50V
C079 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C080 1-126-967-11 ELECT 47µF 20% 50V
C082 1-104-664-11 ELECT 47µF 20% 25V
C083 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C084 1-126-964-11 ELECT 10µF 20% 50V
C085 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C086 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C087 1-126-964-11 ELECT 10µF 20% 50V
C089 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C090 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C091 1-126-933-11 ELECT 100µF 20% 16V
C094 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C095 1-117-722-11 ELECT 2200µF 20% 10V
C096 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C097 1-126-964-11 ELECT 10µF 20% 50V
C098 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C099 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1003 1-104-664-11 ELECT 47µF 20% 25V
C1004 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1005 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C1006 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C1007 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C5002 1-126-964-11 ELECT 10µF 20% 50V
C5003 1-126-933-11 ELECT 100µF 20% 16V
C5004 1-104-664-11 ELECT 47µF 20% 25V
C5005 1-104-664-11 ELECT 47µF 20% 25V
C5008 1-104-664-11 ELECT 47µF 20% 25V
C5009 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5101 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5103 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5105 1-104-664-11 ELECT 47µF 20% 25V
C5106 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5108 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5110 1-104-664-11 ELECT 47µF 20% 25V
C5203 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5205 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5206 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C5301 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5303 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5304 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C5305 1-104-664-11 ELECT 47µF 20% 25V
C5306 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5308 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5310 1-104-664-11 ELECT 47µF 20% 25V
C5401 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5403 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C5404 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C5406 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5408 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C5409 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C5413 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C5501 1-126-967-11 ELECT 47µF 20% 50V
C5602 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C5606 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C5607 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
<CONNECTOR>
CN001 1-784-500-11 CONNECTOR, FFC/FPC 21P
CN002*1-564-511-11 PLUG, CONNECTOR 8P
CN007*1-564-512-11 PLUG, CONNECTOR 9P
CN010 1-784-786-11 CONNECTOR, FFC 25P
CN011 1-784-786-11 CONNECTOR, FFC 25P
CN5001* 1-564-509-11PLUG, CONNECTOR 6P
CN5002* 1-564-511-11PLUG, CONNECTOR 8P
CN5003* 1-564-505-11PLUG, CONNECTOR 2P
<DIODE>
D001 8-719-062-51 DIODE 1PS226-115
D002 8-719-062-51 DIODE 1PS226-115
D003 8-719-062-51 DIODE 1PS226-115
D004 8-719-062-51 DIODE 1PS226-115
D005 8-719-109-89 ZENER DIODE RD5.6ESB2
D006 8-719-109-89 ZENER DIODE RD5.6ESB2
