Connecting the receiver
20
Connection with the S-Video Cable (S-VHS)
Caution!
Strictly follow instructions for connecting the S-video cable
(SVHS) given in the operating manual of your TV set.
The S-Video cable is not included in the scope of supply.
Insert the S-Video cable in the “S-VHS“ socket of the receiver.
Connect the S-Video cable to the TV set.
Insert the Cinch connector of the Cinch cable in the “AUDIO-R“
and “AUDIO-L“ sockets of the receiver.
Connect the Cinch cable to your stereo system.
Insert the SCART cable in the SCART socket “VCR” of the
receiver if you want to connect a video set.
Connect the SCART cable to the video set.
Follow the operating manual of the video set.
Please set “CVBS” for this type of connection under the
menu item "Settings – Audio/Video settings – TV SCART
Mode“.
For sound reproduction you can connect your receiver to a
hi-fi system or an audio digital receiver by alternatively
using the coaxial, digital or optical connection. Additionally
you have the option to connect the device to the TV set by
using the audio connections AUDIO L and AUDIO R if the
TV set offers this possibility.
Please follow the instructions in the manuals of your TV set
and/or your hi-fi system and/or your audio digital receiver.
