Silvercrest SL 65 T User Manual

Technical specifications
59
Receiver
Output level RED 0.7 Vss, 75 ohms
Output level GREEN 0.7 Vss, 75 ohms
Output level BLUE 0.7 Vss, 75 ohms
Teletext
Teletext filter according to ETS 300 472 standard
Reception of Teletext data (FBAS) according to ITU-R BT.653-2,
lines: 6-22 and 320-335
Connection options
TV SCART (output) CVBS and RGB, audio L, R , YUV
(YCbCr)
VCR SCART (output and input) CVBS, audio L, R
RCA Video, audio L, R
COAXIAL, OPTICAL Digital audio output
S-VHS S-Video output
Antenna IN VHF/UHF, 5V/100mA
Antenna OUT VHF/UHF
RS232 9pin D-Sub, bidirectional, 115 kBit/s
software update
Power supply
Input voltage power pack 100-240 V ~, 50/60 Hz
Power consumption approx. 20W in normal mode
approx. 2.8W ( standby)
Operating temperature 0 ºC ~ +40 ºC
Storage temperature -40 ºC ~ +65 ºC

Silvercrest SL 65 T Specifications

General

Brand	Silvercrest
Model	SL 65 T
Category	Receiver
Language	English
