SYSTEM OPERATIONS-22
Generator: The generator set of switches
have the power from the generator com-
ing into these switches then going out to
the 120 Volt AC Panel. The power goes
directly to the AC Main Switch at the 120
Volt AC Main Section.
Transfer: This set of switches get there
power from the generator. The power then
goes from here to the AC Main Breaker
Switch at the Air Conditioning Section of
the AC Panel.
NOTE: Both the Generator and the Air
Conditioning is an option. You may not
have either on your boat.
Shore Power 1: This set of switches gets
its power from the Upper Shore Power
Hook-Up located in the Cockpit Storage
Compartment. The power then goes from
here to he AC Main breaker Switch at
the 120 Volt AC Section of the AC Panel.
The photo below shows the Shore Power
Hook-Up at the Cockpit Storage Compart-
ment.
The Shore Power 1 hook-Up is the upper
Hook-Up. The Shore Power 2 Hook-Up is
right below the Shore Power 1 Hook-Up.
The breakers for each are to the right of
the Hook-Ups.
Shore Hook-Up 2: The power to this set of
switches comes from The shore Hook-Up
at the Cockpit Storage Compartment. The
power goes from here directly to the AC
Main breaker Switch at the Air Condition-
ing Section of the AC Panel.
NOTE: Shore Power 2 is an optional set of
switches for your air conditioning system.
If you did not choose air conditioning as
an option there is no need for the sets of
switches on the right hand side (Transfer
and Shore Hook-Up 2).
If there is no generator, Shore Hook-Up 1
goes directly to the AC Main switch at the
120 Volt AC Section of the AC Panel, and
Shore Hook-Up 2 goes directly to the AC
Main Switch at the Air Conditioning sec-
tion of the AC panel.
GENERATOR (OPTIONAL)
The Generator is located below the cock-
pit fl oor. The photo below shows the
Generator.
There is a breaker for the generator power
above the generator.
