6. Basic Setup
33
Basic Setup
6.
6.8
User sensor configuration
The VIA shows all properly configured user sensors. Each correctly configured sensor will automatically show up on the VIA.
The following section describes how to set up a sensor on the VIA.
6.8.1
Adding a user sensor
In the settings menu, navigate to DEVICES > USER SENSORS.
Select “Add new” and fill in the requested data.
· NAME – Name the user sensor.
· VOLTMETER – Select the voltage input used to measure the analog output of your voltage type user sensor.
· LOW VALUE POINT – What value is presented by the LOW VOLTAGE POINT (see bellow).
· HIGH VALUE POINT – What value is presented by the HIGH VOLTAGE POINT (see bellow).
· RANGE (MIN/MAX) – Determines the color of the bar. At 75% the color of the bar will turn RED.
· DECIMALS – Set an offset of the decimal point (from right to left).
· MEASUREMENT UNIT – Input the measurement unit that will be presented on the display graph.
· LOW VOLTAGE POINT – Expected voltage when the sensor measures its lowest value.
· HIGH VOLTAGE POINT – Expected voltage when the sensor measures its highest value.
· DELETE - With this option, you can delete the selected user sensor.
