8. Panel and Power Unit configuration
57
Panel and Power Unit
configuration
8.
8.1
Configuring a button to display a specific screen
You can configure a button so that a specific monitoring screen will be display when the button is pressed.
The following configurations displays an inclinometer screen when the user presses the button 6 (7).
Navigate to MENU > DEVICES > CONTROL UNIT > SCC8 >
Select BUTTON 6
INSTANCE (the value can remain as it is)
MODE = Set mode to DISPLAY
SCREEN = Select INCLINOMETER
You can configure a button to display INCLINOMETER, TANK or BATTERY screen.
It is also possible to display a specific screen and at the same time toggle a relay. An example of that would be the following
configuration of BUTTON5, which would start the water pump (for instance) and at the same time display the TANK screen.
BUTTON 5
MODE = TOGGLE
SCREEN = TANKS
The changes will take place, when you leave the menus.
8.2
Configuring a button to toggle a different relay
You can configure a button so that a specific monitoring screen will be display when the button is pressed.
The following configurations swaps the functionality of BUTTON 0 (which by default toggles OUTPUT 1) with that of the
BUTTON 1 (which by default toggles OUTPUT 2).
Make sure that the same instance property is not shared by multiple buttons.
Navigate to MENU > DEVICES > POWER UNIT > SPU62 [...] > OUTPUTS.
The default values for BUTTON 0 and BUTTON 1 are:
BUTTON 0
