19-6432-M-01 Rev 4 26
4.1 Specifications
Model 6432e Blower
Input Voltage 24 VDC ±10%, 6W (max) or 24 VAC ±10%; 50/60 Hz, 6W (max)
Discharge
±1000-100V, <4 sec @ 1’ using 24 VAC, tested in accordance with ANSI/
ESD STM3.1-2006 (performance of the Model 6432 will be reduced slightly
when powered with 24 VDC)
Balance ±20V @ 1’ away
Ion Emission Steady-state DC
Emitter Points Tungsten wire; internally shielded; 5-year life
Airflow 49 cfm (typ)
Ozone <0.005 ppm (24-hour accumulation)
LED Indicators Green POWER; red ALARM
Connectors
24 VAC/VDC power input, 8-pin terminal block with 24 VDC input from
process equipment; 4-20 mA current loop FMS output and relay interface
Controls On/off rocker switch
Operating Env. Temperature 10-35°C (50-95°F); humidity 30-60% RH, non-condensing
Dimensions 5.3H x 5.0W x 2.3D in. (13.3 x 12.7 x 5.7 cm) without stand
Weight 16 oz (467g) without stand
Certifications RoHS Compliant
14-1320-01 Transformer
Input Voltage 120 VAC, 60 Hz
Output Voltage 24 VAC, 60 Hz @ 450 mA, ±5%
Short Circuit
Protection
The power supply is provided with protection against short circuit by means
of a primary thermal fuse.
Dimensions 3.4H x 2.3W x 1.9D (87 x 58.5 x 48 mm)
Weight 1 lb (0.45 kg)
Certifications RoHS Compliant
14-1330 Transformer
Input Voltage 230 VAC ±10%, 50 Hz
Output Voltge 24 VAC @ 750 mA, ±5%
Short Circuit
Protection
The power supply is provided with protection against short circuit by means
of a primary thermal fuse.
Dimensions 2.8H x 2.5W x 1.9D in. (72H x 63W x 49D mm)
Weight 0.8 oz (0.36 kg)
