19-6432-M-01 Rev 4 27
Certifications RoHS Compliant
14-1322 AC/DC Adapter
Input Voltage 100-240 VAC ±10%, 50/60 Hz
Output Voltge 24 VDC @ 400 mA
Short Circuit
Protection
The power supply is provided with protection against short circuit by means
of a primary thermal fuse.
Dimensions 1.4H x 2.1W x 3.4L in. (36H x 53W x 86L mm)
Weight 0.25 lb (0.11 kg)
Certifications
RoHS Compliant
Mounting Stands (Optional)
Material/Finish
Aluminum/epoxy-polyester powder-coat (both In-tool and Benchtop
gimbaled bracket/stands)
Depth In-tool 45 mm; benchtop 108 mm
Mounting Holes In-tool, 2 holes 3/16” dia; benchtop, 4 slots 5/8”L x 3/16”W
Mounting
In-tool always mount with screws (two truss head screws included with
blower); benchtop use standalone on table or screw onto walls/ceilings
Stand Screws
Two truss head screws for replacement of mounting stand knobs (both in-
tool and benchtop) are included with blower
Tilt Adjustable Yes (both in-tool and benchtop)
