Simer BW85 Series - Repair Parts List; Parts Identification and Part Numbers

Repair Parts 8
For parts or assistance, call Simer Customer Service at 1-800-468-7867
1
2
3
4
5
6
4
7
8
9
11
12
13
14A
14B
15
16
10
3789 1211
Ref. Description Qty. Part Number
1 Screw, Cover 4
†
2 Cover Plate 1
3 O-Ring 1
4 Wearplate 2
5 Impeller 1
6 Cam Ring 1
7 Seal, U-Cup 1
8 Washer 1
9 Housing Body 1
10 Screw 2
11 Water Slinger 1
12 Motor 1 *
13 Cord Set 1 992-695
14A Fuse Holder 1 U17-1148
14B Fuse (Bussmann ABC-30) 1 344-001
15 Pud-L-Scoop® ** 1 FP000349A
16 Screen, Suction 1 S8-146
† Included in Pump Head Assembly (A267)
* If the motor fails, replace the pump.
** Includes 6’ garden hose and washer
Impeller and Seal Kit (A270) includes Ref. 3,4,5,6, and 7.
