Simoco SDB680 - List of Figures

LIST OF FIGURES
Figure 1: Layout of Rear Panel. 29
Figure 2: 2-pin IP67 DC Power Connector. 30
Figure 3: Mounting holes drilling template (dimensions in mm). 35
Figure 4: Wall Mount Assembly. 35
Figure 5: Keyhole Standoff mounting locations. 36
Figure 6: Base Station secured to Wall Mount. 36
Figure 7: Interface Selection screen. 40
Figure 8: IP Configuration Tool main screen 41
Figure 9: Base configuration page – Base Settings tab. 41
Figure 10: Write Base(s) page. 42
Figure 11: Interface Selection screen. 45
Figure 12: IP Configuration Tool main screen. 45
Doc Number: TNM-I-E-0046 ISSUE 1.2 Page 9
