4. aSSembly inStructionS (cont.)
4.3 Assembly Steps (cont.)
J
Attach garden hose to water supply and turn water on.
K
0º
15º
25º
40º Detergent
Select the desired tip based on the following purposes:
• 0° (Red): Thin and powerful stream of water
for dicult stains and debris
removal.
• 15° (Yellow): Thin-angled spray for detailed
cleaning.
• 25° (Green): Medium-angled spray for detailed
cleaning.
• 40° (White): Large pattern for wider cleaning
applications.
• Detergent (Black): This nozzle must be used when
applying detergents with the
on-board detergent injection
system. Applies detergents in low
pressure only.
To install tip, gently slide the collar back before inserting it,
then release the collar to lock the tip.
Assembly Instructions
