9
4. aSSembly inStructionS
4.1 Surface Preparation
Before beginning any cleaning task, it is important to inspect the
area for objects that could create a hazard. Remove any objects
from the work area that could be tripped over, such as toys or
outdoor furniture. Ensure that all doors and windows are closed
tightly.
4.2 Water Supply (Cold Water Only)
• The unit must be used with cold water supply only. The water
hose must be at least 13 mm (1/2”) in diameter.
• The water ow rate must not fall below 18 litres per minute
LPM (4 gallons per minute GPM), or the pump might be
damaged. The ow rate can be determined by running water
for one minute into an empty container.
• The water supply temperature must not exceed 40ºC (104ºF)
WARNING — INJECTION HAZARD
Pressure washer can cause serious injury if the spray penetrates
the skin. Do not point the gun at anyone or any part of the
body. In case of penetration, seek medical aid immediately.
4.3 Assembly Steps
A
Install the wheel on the wheel receptacle by pressing the
pin on the wheel shaft and align the pin to the hole on the
receptacle.
S
Install the handle assembly on the metal cart by pressing the
pin on the metal cart and align the pin to the hole on the
handle.
Assembly Instructions
