Simoniz sI900 - EASY ASSEMBLY; FIRST TIME USE ONLY; 2; 3

1
EASY ASSEMBLY
1
2
3
Take pressure washer hose extension (11) and attach one end to
the outlet on pressure washer, and the other end to the side of hose reel.
Attach the high-pressure hose from hose reel to the gun.
11
14 15
FIRST TIME USE ONLY
Remove the covers. Separate quick-connect coupling assembly (14 and 15).
Attach inlet adaptor (15) to inlet and attach quick-connect coupling (14) to garden hose.
