Table 6: Maximum distance supported for respective AWG for Annunciator quantity
Maximum
Annunciator QTY
Maximum distance
(ft) w/ 22 AWG
Maximum distance
(ft) w/ 20 AWG
Maximum distance
(ft) w/ 18 AWG
Maximum distance
(ft) w/ 16 AWG
Maximum distance
(ft) w/ 14 AWG
8 310 493 783 1244 1980
7 354 563 895 1421 2263
6 413 657 1044 1658 2640
5 496 788 1253 1990 3168
4 620 985 1566 2488 3960
3 826 1314 2088 3317 4000
2 1239 1970 3132 4000 4000
1 2478 3941 4000 4000 4000
Note:
1. A maximum of eight annunciators are supported on 2250 and 2050 panels.
2. A maximum of four annunciators are supported on 2008 panels.
page 18 579-1434 Rev B
Foundation Series 2606-9101 LCD Annunciator Installation Guide
