3.1 Specifications
• For use indoors in a dry location.
• All connections are power-limited and supervised.
Table 3: Measurements
Height Length Depth
5 3/8 in. 6 7/8 in. 1 3/8 in.
13.65 cm 17.46 cm 3.49 cm
Table 4: Power requirements and environmental limitations
Measurement type Item Range
Voltage 24 VDC power supply Nominal 24 VDC:
Compatibility range, 16 to 30 VDC
When the LCD back-light is off:
Alarm current: 48 mA
Standby current: 40 mA
Current Maximum current
value
When the LCD back-light is on:
Alarm current: 72 mA
Standby current: 65 mA
Operating range 32°F to 120°F (0°C to 49°C)Temperature
Storage range -4°F to 158°F (-20°C to 70°C)
Humidity Relative humidity The equipment operates normally under non-condensing humidity conditions up to 93%
relative humidity at 90°F (32°C).
page 7 579-1434 Rev B
Foundation Series 2606-9101 LCD Annunciator Installation Guide
