The optional city module has disconnect switch(s) SW1 (City Circuit 1) and
SW2 (City Circuit 2) that disables the city circuit if desired. If the AHJ wanted
to test the city box, the city circuit disconnect switch(s) would not be enabled. A
system wired with the optional DACT module must have system testing
coordinated with the Central Station operator and the AHJ.
To initiate a test with the 4004, activate an initiating device (pull station, smoke
detector etc.). The test simulates a real alarm condition. This allows the
building occupants to become familiar with the conditions encountered in an
actual fire emergency condition.
If the 4004 Fire Alarm System has an Alarm, Supervisory, or Trouble condition,
refer to Figure 6 for Emergency Operation procedures.
EMERGENCY OPERATING INSTRUCTIONS
ALARM–SUPERVISORY–TROUBLE CONDITION:
–SYSTEM INDICATOR FLASHING, TONE ON.
TO ACKNOWLEDGE:
–PRESS “ACK” UNTIL TONE ALERT IS SILENCED
–REVIEW FIRE ALARM & TROUBLE INDICATORS
–SUMON APPROPRIATE PERSONNEL TO INVESTIGATE
TO SILENCE ALARM SIGNALS:
–PRESS “ALARM SILENCE”.
TO RESTORE SYSTEM TO NORMAL:
–PRESS “SYSTEM RESET”. SYSTEM RESET WITHIN 15 SEC
A DASH WILL APPEAR IN BOTH FIRE & TROUBLE INDICATORS
WHILE SYSTEM RESET IS IN PROGRESS.
LAMP TEST:
–PRESS “ACK” FOR 5 SEC
Figure 6. Emergency Operating Instructions
System Testing (Fire Drills)
(Continued)
Emergency Operating
Instructions
To Next Page
