Simplex 4007ES User Manual

1-1
Chapter 1
Overview
Introduction The 4007ES fire alarm control panel provides audible and visible indication of alarms,
troubles, and supervisory conditions. The 4007ES panels supports addressable notification
and initiating devices and the 4007ES Hybrid panels supports non-addressable notification
devices and addressable initiating devices*. The panel can be configured by using a panel
programmer.
*From this point on, the 4007ES and the 4007ES hybrid will be referred to as 4007ES, unless
stated otherwise.
4007ES operator instructions are described in the 4007ES Operator’s Manual, 579-1165.
4007ES programming instructions are described in the 4007ES Programmer’s manual,
579-1167.
In this chapter
4007ES Product List ............................. 1-1 Glossary ................................................ 1-2
User Interface........................................ 1-2
4007ES Product
List
Part Number
Base Panels
4007-9101
4007ES Hybrid, Red
4007-9201
4007ES, Red
4007-9102
4007ES Hybrid, Platinum
4007-9202
4007ES, Platinum
Part Number
Optional Modules: Field Installed
Manual
4007-9801
Zone/Relay Module 579-1103
4007-9802
25V Regulator Module 579-812
4007-9803
IDNet+ Loop Expansion Module 579-1106
4007-9804
Dual Class A Module 579-1029
4007-9805
LED Module 579-1105
4007-9806
DACT Module 579-954
4007-9807
City Circuit with Disconnect Module 579-955
4007-9808
City Circuit without Disconnect Module 579-955
4007-9809
Relay Module 579-955
4190-6106
TrueInsight Remote Service Gateway and Programming 579-953

Simplex 4007ES Specifications

General

Model	4007ES
Category	Fire Alarms
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Display	4.3-inch color touchscreen
Power Supply	120/240 VAC, 50/60 Hz
Network Connectivity	Ethernet, RS-232, RS-485
Addressable Points	250
Communication Protocols	MAPNET II
Notification Appliance Circuits	4 NACs
Total Points	250
Annunciation	Yes
Max Devices	250
Max Notification Circuits	4
Communication Ports	RS-232, USB
