7 S4100-0031-21 12/2012
Miscellaneous Accessories
Model Description
4100-1279
Single blank 2” display cover; 4100-2302 provides a single plate for a full bay
4100-9856* 4100ES Canadian French Appliqué Kit; Simplex, 4100ES, Controle Incendie
4100-9857* 4100ES English Appliqué Kit; Simplex, 4100ES, Fire Control
4100-9858* 4100ES InfoAlarm Remote Display English Appliqué Kit; Simplex, Operator Interface, 4100ES
4100-9859* 4100ES InfoAlarm Remote Display Canadian French Appliqué Kit; Simplex, Interface de l’operateur, 4100ES
4100-9835 Termination and Address Label Kit (for module marking); provides additional labels for field installed modules
4100-6029
Smoke Management Application Guide; required for UUKL listing
4100-6034
Tamper Switch, one per cabinet assembly if required; monitors solid door for panels with solid door; monitors the
internal retainer panel for panels with glass door (not the glass door); has a built-in addressable IDNet IAM
2081-9031
Series resistor for WSO, IDCs (N.O. water flow and tamper on same circuit, wires after water flow and before tamper)
470 Ω, 1 W, encapsulated, two 18 AWG leads (0.82 mm
2
), 2-1/2” L x 1-3/8” W x 1” H (64 mm x 35 mm x 25 mm)
* Note: 4100ES English Appliqués are included with 4100ES Upgrade and Retrofit Kits for mounting 4100ES in 4100, 2120, 2001,
and Autocall back boxes so that upgrades can be easily identified as 4100ES. 4100ES Appliqué Kits are available for
applications such as to update Remote InfoAlarm Displays connected to a panel that was upgraded to 4100ES or for an
existing 4100U when the New Master Controller is upgraded to 4100ES and only a software upgrade is required. When
required, French appliqués are ordered separately.
Addressable Interface Modules (refer to location reference on pages 8 and 9)
Model Description Supv. Alarm
4100-3101 IDNet Module, 250 point capacity With 250 IDNet devices, add 200 mA 250 mA
4100-3104 IDNet Module, 127 point capacity With 127 IDNet devices, add 102 mA 127 mA
4100-3105 IDNet Module, 64 point capacity With 64 IDNet devices, add 51 mA 64 mA
IDNet Modules, Specifications for each capacity;
Module size = 1 Block
Module without devices 75 mA 115 mA
Loading per IDNet device 0.8 mA 1 mA
Model Description Supv. Alarm
4100-3102
MAPNET II Module, 127 point capacity, add devices
separately; Module size = 2 Slots;
Loading per MAPNET II device = 1.7 mA
Module without devices 255 mA 275 mA
Fully loaded module, total 471 mA 491 mA
4100-3103
Isolator Module for MAPNET II or IDNet; converts a single connected SLC into four
isolated outputs selectable as Class A or Class B; up to two Isolator Modules can be
connected to one SLC; Module size = 1 Slot;
NOTE: Compatible with MAPNET II Remote Isolators only; for quad isolation with IDNet
Remote Isolators, use 4100-3107 IDNet+ Module (see data sheet S4100-0046 for details)
50 mA 50 mA
Relay Modules; Nonpower-limited (for mounting in expansion bay only, refer to location reference on pages 8 and 9)
Model Description Resistive Ratings Inductive Ratings Size Supv. Alarm
4100-3202 4 DPDT w/feedback 10 A 250 VAC 10 A 250 VAC 2 Slots 15 mA 175 mA
4100-3204 4 DPDT w/feedback 2 A 30 VDC/VAC 1/2 A 30 VDC/120 VAC 1 Block 15 mA 60 mA
4100-3206 8 SPDT 3 A 30 VDC/120 VAC 1-1/2 A 30 VDC/120 VAC 1 Block 15 mA 190 mA
Current Calculation Notes:
1. To determine total supervisory current, add currents of modules in panel to base system value and all external loads powered
by panel power supplies.
2. To determine total alarm current, add currents of modules in panel to base system alarm current and add all panel NAC loads
and all external loads powered from panel power supplies.
Module Selection Information (Continued)
