Simplex 4100ES Quick Start Guide

6 S4100-0031-21 12/2012
Master Controller Upgrades for Existing 4020 Series Fire Alarm Control Panel
Model Description
4100-9833
4020 Master Controller Upgrade to 4100ES; Includes New Master Controller with LCD & operator interface assembly,
8 VDC Converter and RUI Interface in a single bay cabinet with locking glass door and retainer; mounts as an adjunct
panel close-nippled to existing 4020 cabinet; also includes 8 VDC box-to-box power and communications harness and
solid filler panel for the existing 4020 Master Controller bay
Communication Modules
Model Description Size Supv. Alarm
4100-6078 For Master Controller; mounts in Slot 3
Modular Network Interface; each requires
two media modules (below)
1 Slot 46 mA 46 mA
4100-6061 For Redundant Master Controller 1 Slot 46 mA 46 mA
4100-6056 Wired Media Module
Select two media cards as required; mounts on
4100-6078 or 4100-6061
N.A. 55 mA 55 mA
4100-6057 Fiber Optic Media Module N.A. 25 mA 25 mA
4100-6047 Building Network Interface Card (BNIC), refer to data sheet S4100-0061 for details 2 Blocks 291 mA 291 mA
4100-6055
Network Access Dial-in Service Modem, mounts to 4100-6078 or 4100-6061 Network
Interface Card, requires telephone line connection
N.A. 60 mA 60 mA
4100-1291 Remote Unit Interface Module (RUI); up to three maximum per control panel 1 Slot 85 mA 85 mA
4100-6030
Service Port Modem, local panel access only, mounts to Master Controller Module,
requires telephone line connection, accesses same information as front panel port
N.A. 70 mA 70 mA
4100-6031
Select one per
SPS (fits on SPS)
City Circuit, with disconnect switches
For use with SPS
only, not RPS
N.A. 20 mA 36 mA
4100-6032 City Circuit, w/o disconnect switches N.A. 20 mA 36 mA
4100-6033 Alarm Relay, 3 Form C relays, 2 A @ 32 VDC; for SPS or RPS N.A. 15 mA 37 mA
4100-6101 Physical Bridge, Class B, includes 1 modem module and 2 wired modules 1 Slot 210 mA 210 mA
4100-6102 Physical Bridge, Class X, includes 2 modem and 2 wired modules 2 Slots 300 mA 300 mA
4100-6038 Dual Port RS-232 with 2120 interface (slot module)
3 maximum of RS-232 type
modules per panel
1 Slot 132 mA 132 mA
4100-6046 Dual Port RS-232 standard interface (4 x 5 module) 1 Block 60 mA 60 mA
4100-6045 Decoder Module 3 Slots 85 mA 163 mA
4100-6048 VESDA Aspiration System Interface 1 Slot 132 mA 132 mA
4100-6052
DACT, Point or Event Reporting; 1 shipped unless 4100-7908 is selected; 2 max. per
system; includes 2, 2080-9047 cables, 14 ft (4.3 m) long, RJ45 plug and spade lugs
1 Slot 30 mA 40 mA
Expansion, System, Remote, and TrueAlert Power Supplies and Accessories (Canadian models have low battery cutout)
Model Voltage/Listing Description Size Supv. Alarm
4100-5101 120 VAC UL
Expansion Power Supply (XPS); 9 A output, 3 built-in
Class A/B NACs; NAC operation is same as SPS, see
page 5 for details
2 Blocks 50 mA 50 mA
4100-5103 120 VAC, Canadian ULC
4100-5102 220-240 VAC UL
4100-5115 NAC Expansion Module, 3 NACs, Class A/B, mounts on XPS only N.A. 25 mA 25 mA
4100-5111 120 VAC UL
Additional System Power Supply (SPS); 9 A power
supply/charger with 250 point IDNet channel, 3 Class
A/B NACs, add IDNet device currents separately
4 Blocks 175 mA 185 mA
4100-5112 120 VAC, Canadian ULC
4100-5113 220-240 VAC UL
4100-5125 120 VAC UL
Remote Power Supply (RPS); 9 A power
supply/charger similar to SPS except no IDNet channel
or City Circuits; will accept one 4100-6033
4 Blocks 150 mA 185 mA
4100-5126 120 VAC, Canadian ULC
4100-5127 220-240 VAC UL
4100-5120 120 VAC UL
TrueAlert Power Supply (TPS); 3 Class B SLCs rated
3 A each for up to 63 TrueAlert addressable (special
application) appliances per channel, 189 per TPS;
built-in battery charger; 2 A aux. power output; add
device current separately (see S4009-0003 for details)
4 Blocks
88 mA 100 mA
4100-5121 120 VAC, Canadian ULC
4100-5122 220-240 VAC UL
4100-5124 TrueAlert SLC Class A Adapter for all 3 SLCs, mounts on TPS only N.A. 10 mA 10 mA
4100-5152 12 VDC Power Option, 2 A maximum 1 Block 1.5 A maximum
4100-0156 8 VDC Converter, required for multiple Physical Bridge Modules, 3 A maximum 1 Block included w/loads
4009-9813
4009 TPS Transponder Interface Card (TIC), mounts in a remote cabinet with TPS; order card, TPS, and batteries
separately, and select a 2975-9229 (red) or 2975-9230 (beige) cabinet (field installed); refer to data sheet S4100-0037
for cabinet detail; Supervisory and Alarm current = 87 mA; (CSFM listed under 7300-0026:0368)
4100-0636 Box Interconnection Harness Kit (non-audio); order one for each close-nippled cabinet
4100-0638 4100 Slot Module Additional 24 VDC Harness; need when 4100 Slot module requirements exceed 2 A from SPS
8 Zone Initiating Device Circuits* Expansion Signal Module and Options (1.5 A Class B except as noted)
Model Type Supv. Alarm Model Description Supv.
A
larm
4100-5005 Class B 75 mA 195 mA 4100-5116 Converts 1 NAC in to 3 NACs out; 1 Block size 18 mA 80 mA
4100-5015 Class A 75 mA 195 mA 4100-1266 Expands 3 NACs to 6
select one; mounts
on 4100-5116
0.6 mA 60 mA
* IDC Modules are 1 Slot size 4100-1267 Converts 3 NACs to Class A 0.6 mA 30 mA
Continued on next page
Module Selection Information

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
