Connect Simrad NX40 / NX45, Northstar M84 / M121 | 43
6.1 Parts needed NX40/45 and M84/M121
Qnt. Item Description Part No.
1
Open array scanner. For part numbers (see "Check the radar parts" page 10)
Radar Processor
Qnt. Item Description Part No.
1
Radar Processor: One of
the following
6 kW processor
10 kW processor
25 kW processor
AA010014
AA010015
AA010016
If you're connecting the radar to a Simrad NX40/NX45 or a Northstar M841 or M121, you need
the AA010112 connection kit or serial connection cable AA010114 (NX40/45 with heading via
SimNet). These are not supplied as standard and must be ordered separately.
Radar connection kit AA010112
Qnr Item Description Part No.
Radar connection kit AA010112
1
HD Radar serial comms
cable 3 m (9.75 ft)
Radar processor heading
sensor/display Y cable
Radar processor NMEA in
cable 250 mm (9.75")
AA010114
AA010113
AA010116
6 Connect Simrad NX40 / NX45, Northstar M84 / M121

Simrad 6kW Specifications
