Simrad 6kW - 6.2 NX40;45 M84;M121 Radar Connections

44 | Connect Simrad NX40 / NX45, Northstar M84 / M121
Heading sensor (optional)
Qnt. Item Description Part No.
1
FC40 Fluxgate Compass
OR
RC42 Rate Compass.
These have a 5.5 m (18 ft)
SimNet cable attached.
Connect using the radar
accessories kit.
Alternatively use an NMEA
0183 heading sensor and
connect via display unit
power cable.
22090187
22090195
6.2 Simrad NX40/45 Northstar M84/M121 radar connections
