Connect Simrad NX40 / NX45, Northstar M84 / M121 | 45
A Scanner Scanner comes with a 20 m (65.5 ft) cable (B) that needs to be attached.
For part numbers (see "Navico radar part numbers" page 73)
B 6kW AA010092
10kW & 25kW
AA010093
Scanner cable 20 m (65.5 ft). Will require disassembly of scanner to
connect. Cable has a radar processor connector on one end, and three
small terminated flat connectors on the other. Optional 30m (99 ft) also
available for 10 kW and 25 kW scanners (AA010094)
CAUTION: This cable should only be installed by an experienced radar
service technician!
C 6 kW AA010014
10 kW AA010015
25 kW AA010016
Radar processor. No cables supplied. Connects to displays via RS485
protocol, using optional radar connection cable kit. The 6 kW system is 12
V or 24 V DC. The 10 kW and 25 kW are 24 V DC ONLY
D AA010150
AA010169
AT40 SimNet to NMEA0183 converter. Supplied with NX40.
AT45 SimNet to NMEA0183 converter. Supplied with NX45.
Converts SimNet data to NMEA 0183. Data from the SimNet such as
position and heading is passed into the NX unit to allow for accurate chart
overlay. Note: If there is no heading sensor on SimNet, chart overlay can
be achieved when the boat is underway and moving at a speed greater
than 1 knot.
The AT40/AT45 has two SimNet ports and a 2 m (6 ft) cable terminating
with 8 pin female connector. This plugs into socket labeled GPS on the
NX40 NX45 display.
AA010112 HD Radar Connection Kit
E AA010114 HD radar serial comms cable 3 m (9.8 ft):
This cable connects the NX display unit to the radar processor. The cable
has a 8 pin female connector on one end which attaches to the port
labeled RADAR on the NX unit. The other end has a 12 pin female
connector which connects to the port labeled NMEA / COMMS on the radar
processor
F AA010113 Heading sensor Y cable, optional method:
Single end has a 12 pin female which connects to HD radar processor port
labeled NMEA /COMMS.
Connector 1 has a 12 pin male. Cable E connects to this then to the NX
display.
Connector 2 has a 8 pin male and connects to cable G which terminates in
bare wires.
G AA010116 NMEA Receive Cable, optional method:
250 mm has an 8 pin female that connect to the cable F. The other end
has bare wires. Black is NMEA IN negative. White is NMEA IN positive. This
connects to the NMEA 0183 heading sensor (NMEA out). A junction box
may be required.
F 700-4100-001 Navico GS10 SimNet GPS antenna. Can ship with NX unit depending on
part number of display (see below).
The antenna has a 5 m (16.5 ft) SimNet cable attached.
Installation note. The SimNet backbone needs to be planned to go within a
5 m cable run of the antenna.
G 22090195 RC42 Heading sensor (or use SimNet heading output from an autopilot). A
heading sensor is optional when using an NX. If there is no heading
sensor, course over ground from the GPS is used.
H
Simrad NX40 or NX 45 or Northstar M84 or M121.
To Next Page
