Specifications | 69
Gain Minimum 90 dB
Noise figure NJT1969 @ 6 dB (average) at front-end input
Temperature range +5ºF to +131ºF (-15ºC to +55ºC)
Relative humidity 93% at +104ºF (+40ºC)
Relative wind velocity 118 ft (36 m)/sec (maximum 70 knots)
6 kW Radar processor specifications
Processor dimensions Width 5.6" (142 mm)
Height 2.2" (56 mm)
Length 7.9" (200 mm)
Processer weight 1.9 lbs (870 g)
Vibration EN60945
Waterproof No rating
Temperature range +5ºF to +131ºF (–15ºC to +55ºC)
Relative humidity 95% at 104ºF (+40ºC)
Power up time Approximately 35 seconds
DC input 10.8 V to 36 V DC
Power consumption 3 W (when operating)
Leakage current <200 µA (when off, with a remote power input)
11.2 Radar system specifications: 10 kW
Radar Type NS-004793
Scanner type Open array
Radar Model Simrad Northstar
TX10s NS004793
DC input 21.6 to 41.6 V (24 V DC systems ONLY)
Scanner dimensions 1.5 ft high (448 mm) x rotation circle 6.25 ft (1910 mm)
Scanner weight 77.2 lb (35 kg) ± 10%
Vibration Amplitude 2 x 13.2 Hz, ± 1 mm ± 10%
Amplitude 13.2 Hz to 100 Hz, gravity acceleration 0.7m/sec²
Waterproof IPX6
Plane of polarization Horizontal
Preheating time Minimum 90 seconds
Power consumption 250 W (maximum) at maximum wind velocity
Emission type P0N. Passed JRC FCC/IC/R&TTE Type Certification:
FCC ID: CKENKE2102
IC ID: 768C-NKE2102
R&TTE: QQ-RTTE-17/03-01R
Peak power output 10 kW ± 50% under any pulse condition
Transmitter frequency 9410 MHz ± 30 MHz
Transmitter tube Magnetron NJRC Model MSF1425B
Horizontal beam width 1.2º ± 10% (-3 dB width)
Vertical beam width 20º ± 20% (-3 dB width)
Side lobe level Below -26 dB maximum (within ± 10º)
Below -30 dB maximum (outside ± 10º)
Rotation rate 27 rpm (minimum 20 rpm at 100 knot wind maximum)
