50 | Connect Northstar 6000i / 6100i
NMEA 2 OUT
GROUND
10 Black Black 12 Yellow
RS-232 GROUND 17 Tan Tan 1 White
RS-232 RX 16 Green Green ** 3 Green
RS-232 TX 18 Red Red ** 8 Red
REMOTE SAVE 13 Orange/White Orange/White
6000i or 6100i
REMOTE POWER OUT
14 Pink Pink
SHIELD 9 Drain Drain 9 Drain
RADAR REMOTE
POWER IN
White/Orange 10 Brown
* See cautions above.
** See cautions above.
The end view of the (three) 3 connectors are shown:
6000i/6100 connector NMEA pin
assignments
Connector 1 - Radar
NMEA/Communications pin
assignments
Connector 2 - SmartCraft pin
assignments
