28 | Installation
Instrument
Instrument
Termination
plug
Wind
transducer *
T-joiner
AT45
Multijoiner
Compass
NX45
5,5 m
5,5 m
1,0 m
2
0
m
/
3
0
m
/
4
0
m
5,5 m
5,5 m
Active
depth
transducer
Analog
Speed/Temp
sensor
Autopilot
24AP
MODE
MENU
AUTO
STBY
TURN
10
10
PWR
1
1
RF25 Rudder Feedback
12V SimNet supply
(SimNet cable without terminator)
Autopilot Computer
Non SimNet
SimNet backbone
SimNet drop cable
Figure 2-21 SimNet network, medium system
