Chapter 1-6 CR34/44/54 Introduction and safety summary
1.3.2 Radar and radar functions
RADAR
Press the [RADAR] key to call up a radar display. Press again to
toggle between the radar shortcut series
- see display examples in section 1.3.1.
To start the radar
1. Press [ENT], [RADAR] to initiate a warming up period of two minutes
(countdown of 120 seconds), and then the radar will go in Standby mode.
2. Press [ENT], [GOTO] to start transmission.
Select and adjust radar range
Press one of the numeric keys 1 - 9 to select a fixed range. Key 9 will select
the largest range and key 1 the smallest.
ENT
Press [ENT] to call up the Radar quick menu with access to e.g.
Overlay Chart, Overlay User Data, activate EBL-VRM cursors, start
and stop radar transmission, etc.
EBL
Toggle the EBL-VRM1 cursors on/off directly from the [EBL] key.
CLR
Turn off cursor. Long press on [CLR] will turn off all cursors on the
radar screen.
ADJ
The [ADJ] key will open for adjustment of the radar parameters.
Use the cursor or the [ADJ] key to move around in the control panel;
toggle between available values with the +/- keys or enter new values
with the numeric keys. Press [ENT] to exit control panel.
In the Dual Radar display: after pressing the [ADJ] key to access the
control panel, only half of the parameters will be visible. By pressing
[ADJ] again will toggle between the 1st and 2nd half of the control
panel.
1.3.3 Chart and chart functions
CHART
Press the [CHART] key to call up a chart display. Press again to
toggle between the chart shortcut series
- see chart examples in section 1.3.1.
C-MAP cartridges (standby)
Press [MENU], [7], [CHART] whenever inserting or removing a C-MAP card.
