CR34/44/54 Setup menu Chapter 9-1
9. Setup menu
7
SETUP
RADAR
Radar setup - see section 9.1
CHART
C-MAP cartridges - see section 9.2
PILOT
Pilot/Position setup - see section 9.3
1
Speed alarm, units & language - see section 9.4
2
Interface setup - see section 9.5
3
Palette setup - see section 9.6
4
Factory settings - see section 9.7
5
QuickGuide - see section 9.8
9.1 Radar setup
After the installation is completed, check the Radar setup to see
if the Antenna height is correct and the Heading adjust is zero
degrees to ship’s center line. If not, then they need to be corrected -
see further ahead in this section. All default settings from the factory
are tested for various situations, however, if your situation is such
that adjustments are required, please refer to the details described in
this section. The Scanner type is preset to Auto detect and as such,
the system will automatically initiate the correct parameters for the
connected scanner.
MENU
Call up the menu bar, and...
7
activate the SETUP menu, and...
RADAR
load the Radar setup
- see example of Radar setup next page.
You will now receive a warning that you are about to change settings
for the radar. Press [ENT] to Continue, or [MENU] to Abandon.
Use the cursor key to move around in the settings. Toggle between
available values with the +/- keys, and insert data by the numeric keys.
ENT
Confirm the adjustments by [ENT] or [MENU]
