Chapter 4-18 CR34/44/54 Chart menu and INFO windows
+/-
Toggle between available settings
ENT
Confirm changes and return to chart, or...
MENU
Abandon Chart setup and return to chart without making any
changes
4.5.1 Display modes in the chart setup
There are 7 different display modes to choose from: FULL (default), CUSTOM,
SIMPLE, FISHING, LOW, GRID, and a special OVERLAY mode, which only
can be activated from the radar function - see section 3.2.7. When a group is
shown in red or a function is shown in light grey it means that it is not available in
the selected display mode. The default settings in the various display modes are:
Group: General - specification of chart display in general
The available functions are according to display example on previous page for
all display modes and any change of the default settings will be applied in all
display modes, except for GRID, which has three adjustable functions:
Motion = RELATIVE
Cursor 5 min. time-limit = ON
Show range = WITH BACKGROUND
Group: Presentation - specifies presentation of marine, land and chart topics
The default settings in this group are fixed in all display modes, except for
*Custom where it is possible by the user to turn a feature ON (shown on the
chart) or OFF (not shown on the chart), etc.
C-MAP features are not available in GRID display mode.
C-MAP features
Full *Custom Simple Fishing Low
Marine:
Names
Nav-Aids
Light Sectors
Attention Areas
Tides, currents
Nature of seabed
Ports
Tracks, routes
Buoys
Signals
ON
INT
ON
ON
ON
ON
ON
ON
ON
ON
ON
INT
ON
ON
ON
ON
ON
ON
ON
ON
ON
INT
OFF
ON
ON
OFF
ON
OFF
ON
ON
ON
INT
OFF
ON
OFF
ON
OFF
OFF
ON
ON
OFF
INT
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
.....continued next page....
