Simrad CR44 User Manual

◄
GOTO
Navigation Compass
PLOT
►
Water depth input:
Group selection: SIMRAD
Source (multiple available):
Simrad EQ44-2 ,Sn:100003
Water temperature input:
Group selection: SIMRAD
Source (one available):
Simrad EQ44-2 ,Sn:100003
Water temperature offset: +0.0°C
Water speed input:
Group selection: SIMRAD
Source (one available):
Airmar EQS ,Sn:000000
LOG speed cal.: 019000 PULSES/nm
NMEA0183 output:
Water temperature: MTW ON
Water speed and heading: VHW ON
Depth: DPT ON
Depth below keel: DBK OFF
Depth below surface: DBS OFF
Depth below transducer: DBT OFF
MENU
Exit Accept
ENT
∆
∆
Water
CR34/44/54 Setup menu Chapter 9-15
PLOT
Go to Water interface - step back with [GOTO]
Water temperature offset - a figure can be keyed in to compensate
for differencies in temperature sensor.
LOG speed calibration - the unit is preset to receive 19000 pulses
per nautical mile from the log transducer (paddle wheel). However
the figure might have to be changed to compensate for various trans-
ducers and actual water flow passing the transducer. The correct
pulse rate is calculated by:
19000 x indicated speed (e.g. 4kn)
= 15.200 pulses/nm
actual speed (GPS) (e.g. 5kn)
NMEA0183 output - see also section 9.5.1 Description of sentences.
