Chapter 2-4 CR34/44/54 Fundamentals & initial start-up
CHART
Shortcut to Chart function. Short press will toggle between differ-
ent data fields on chart. Long press will toggle between Chart in full
screen, Dual Chart, and two custom screens.
ECHO
Shortcut to Depth & temperature diagram and a custom screen.
PILOT
Shortcut to Pilot displays. With navigation mode inactive: short
press will toggle between Highway, Position, Dual Speed and Set &
Drift displays. With navigation mode active: short press will toggle
between Highway, Position, Dual Speed, ETA & AVN, Trim &
Highway, and Set & Drift displays. Long press will toggle between
Pilot full screen and two custom screens.
PAGE
Toggles between active pages under the four main function keys
i.e. [RADAR], [CHART], [ECHO] and [PILOT]. Long press starts
automatic rotation of these pages. Press any key to stop rotation.
ADJ
Gives access to setup displays related to active display. Scrolls
through adjustable parameters.
EBL
Toggles EBL-VRM1 on/off. The Electronic Bearing Lines may be dis-
played in either degrees Relative “R” (to ship’s centerline) or True “T”
(Relative to north), depending on the selected orientation (HU or NU).
WIN
Toggles between active windows in split screen. The active window
will have a solid red frame. Only active windows are operable.
0-9
The alphanumeric keys inserts and selects data in data displays.
Keys 1-9 are also Quick-range keys, which each represent a fixed
radar or chart range. Key 0 will center the cursor/ship on the chart,
and activate/deactivate ‘off-center to cursor’ on the radar display.
CLR
Deletes data in enter or edit mode. Turns cursor off in active display.
Long press will turn off all active cursors on radar display.
From radar control menu: Returns Tune, Gain or Sea to AUTOmatic
mode, and clears the EBL and VRM readings.
PWR
Power on - hold key depressed till you have a picture on the screen.
Calls up a window where you can adjust the brightness in the screen,
background light in keypad, and select Daylight displays, Night
display or custom made color palettes. Hold two seconds to turn the
power off.
