Simrad EQ44 User Manual

◄
GAIN-
Position Navigation
GAIN+
►
+ 1: Simrad EQ44 ,Sn:100003
+ 2: Simrad CA34-3 ,Sn:0070B0
+ 3: Airmar EQS ,Sn:000000
+ 4: Simrad RC35 ,Sn:000035
- : NMEA-PORT
MENU
Exit Accept
ENT
∆
∆
Nodes
Additional
data
No addi-
tional
data
Internal
serial
number
Automatically assigned
network address
Product model numbers (top line is own unit); -1, -2, -3
etc. indicates multi sources. NMEA-PORT indicates
incoming data via the NMEA port.
Chapter 10-8 EQ44/54 SETUP menu
(products) operating on the SimNet bus. See below example:
Move the cursor up/down to select one of the listed products
+
Press the [+] key to access additional data
Example:
• EQ44 ECHO SOUNDER
• SimNet number =100003, Address: 1
• Device: class = 60, function = 130
• Instance: system = 0, device = 0
• SimNet:Compatible=YES,Ver= 1.000 E
• Ver.: NMEA2000 = 1.004, SW = 02.02
• Product code=FFFF,Unique no=138003
The name ECHO SOUNDER can be user defined - see the Identifica-
tion interface (last tab).
-
Press the [-] key to hide additional data
General information: Go to the next interface by pressing [GAIN+]
and step back to the previous interface by pressing [GAIN-].
Use the cursor key to move around in the display and toggle between
available settings and sentences with the +/- keys.
ENT
Confirm editing, or...
MENU
exit function without making any changes
