PAGE | 6
COMPONENT OVERVIEW
HALO 5000 pedestal
C
B
A
E
D
F
G
H
I
Description
A Antenna platform
B Performance monitor antenna
C Transceiver module
D Performance monitor module
E Main gear
F Motor and gearbox assembly
G Ethernet plug
H Safety switch
I Power plug
