Technical specications | 141
6 Technical specications
MX51x Control and Display Unit (CDU)
Display:
Pixels: 6.4 inch, 1/4 VGA 320 x 240
LCD: Black and White STN. Matches polarized sun glasses.
Viewing dir.: 6 O’clock.
Back light: CCFL
Keyboard:
Type: Tactile silicone rubber
Contact: Carbon
Back light: Yellow LEDs
Front enclosure:
Plastic: Black ABS/Plastic
Back enclosure:
Plastic: Black ABS/Plastic with EMI conductive spray
Connectors:
Power/Data: 12-Pin Male (LTW)
Antenna: 10-Pin Female (LTW)
AUX : 8-Pin Female (LTW)
LAN : RJ-45
Rear USB: USB 2.0
Front USB: USB 2.0
For MX512 model (Only)
VGA : 15 Pin D-Conn.
Multi-Port NMEA : 44-Pin D-Conn.
Cables:
Power/Data: 12-wire (Female Connector), 3 meters
Auxiliary: 8-wire (Female connector), 3 meters
Antenna: 10-Wire (F-F 10-Pin LTW connectors) cable
Antenna Cable Lengths: 3, 20, 40, 60 or 80 meters (order as needed)
LAN Crossover Cable: 2 meters RJ-45 cable Asssembly
For MX512 model (Only)
VGA Cable: 2 meter with 15-Pin D-connectors
44-Pin Multi-NMEA Cable: 2 meter with 44-Pin D-connector and 44-Pin Header
connector
