CZone connection to NMEA 2000 | NSS Installation Manual
to commence update. Do not remove the Micro SD card or repower the NSS until the process
is completed (this will typically take no more than a couple of minutes).
NMEA 2000 and Ethernet device updates
To update SimNet and ethernet devices select the Upgrade option presented when the le
is highlighted, followed by conrmation of the device you wish to upgrade. Do not interrupt
the upgrade process.
Touch Screen Calibration
1. Turn the unit o
2. Press and hold the MENU key, then turn the unit on
3. Hold the MENU key during power on, until the calibration utility screen comes up
4. Touch crosshair shown on screen to perform nine point calibration
5. After successful calibration the unit will return to normal application screen
