Specications | NSS Installation Manual
Multi Function Display NSS7 NSS8 NSS12
Display
Display resolution 480 x 640 (H x W) 800 x 600 (H x W) 1024 x 768 (H x W)
Display type 6.4 inch VGA color TFT LCD 8 inch SVGA color TFT LCD 12.1 inch XGA TFT LCD
Display brightness 1200 nits 1200 nits 1200 nits
Touch screen Yes
Power
Power supply 12 - 24 V DC (9-32.0 V DC min - max) 12 - 24 V DC (9-32.0 V DC min - max) 12 - 24 V DC (9-32.0 V DC min - max)
Power consumption 10.4 W (0.8 A @ 13 V DC) 15.6 W (1.2 A @ 13 V DC) 26 W (2.0 A @ 13 V DC)
Technical / Environmental
Housing Plastic housing; Die cast rear heatsink
Temperature -15° C to + 55° C (+5° F to +131° F)
Waterproof standard IPx7
Certicate of conformity CE(EN60945: 2002) / C-tick / CSS
Interface
Ethernet 1 Port 1 Port 3 Ports
NMEA 2000 Micro-C (1)
Video input Composite video (2) (multiplexed)
Data card slot Micro SD (1)
Other
Weight (display only) 1.6 kg (3.5 lb) 2.1 kg (4.6 lb) 3.78 kg (8.3 lb)
Pack dimensions (L x W x H) 30.5 x 27.9 x 27.9 cm (12" x 11" x 11") 40.6 x 27.9 x 25.4 cm (16" x 11" x 10")
Pack weight 2.54 kg (5.6 lb) 2.9 kg (6.5 lb)
Echo sounder
Sonar frequency 50/200 or 83/200 kHz 50/200 or 83/200 kHz Not applicable
Sonar output power Max 250 W peak to peak (31 W RMS)
actual
Max 250 W peak to peak (31 W RMS)
actual
Not applicable
Specications
21
