Simrad RI9 Rudder Angle Indicator
18 20220562E
VOLTAGE FB
SUPPLY +
3x1,5 sq.mm
3x1,5 sq.mm
TOTAL NUMBER OF INDICATORS: 8
RUDDER ANGLE INDICATORS
RI9 RI9 RI9
PANORAMA
123456
2x1,5 sq.mm
MAINS
110-220V 50-60Hz
RI4
RECTIFIER BOX
STANDARD
RUDDER POT. METER
123
110V
220V
1 23456
3
1
2
SEPARATE LAMP SUPPLY
SUPPLY -
VOLTAGE FB
SUPPLY +
SUPPLY -
VOLTAGE FB
SUPPLY +
SUPPLY -
Fig. 2-7. Wiring diagram
Panorama and RI9 on AC Mains using a Robertson RI4 Rectifier and
“standard rudder potentiometer”
