Simrad RS10U User Manual

30
Simrad RS10 Operation and Installation Manual
5-2-9 Request the LL Position of a Buddy (LL REQUEST)
1. Press CALL/MENU to enter DSC mode, then select LL REQUEST.
2. Select the buddy whose LL position you want to request then press ENT to send the request. (See
Section 5-3-5 for the acknowledgement.)
3. The working channel name is displayed while the radio waits for an acknowledgement from your
buddy. If there is no reply after 1 minute the radio asks if you want to retry. Continue as explained
in Section 5-2-2.
5-3 Receiving DSC Calls
Several types of DSC calls can be received from vessels within range at various priority levels:
DISTRESS See Section 6.
ALL SHIPS Urgency or Safety priority (see Section 5-3-1)
Note: In some countries, ALL SHIP DISTRESS calls are received.
INDIVIDUAL Urgency, Safety, or Routine priority (see Section 5-3-2)
Note: In some countries, INDIVIDUAL DISTRESS RELAY calls are received.
GROUP Routine priority only (see Section 5-3-3)
GEOGRAPHIC Routine priority only (see Section 5-3-4)
POLLED POSITION Routine priority only (see Section 5-3-5)
In addition to the audible alert, the telephone icon will ash on the screen.
5-3-1 Receiving an All Ships Call (ALL SHIPS)
1. When you receive notication of an ALL SHIP call, press any key to
cancel the alert. The radio automatically selects CH16.
The priority level and the user MMSI are displayed on the screen. If the
radio recognises the user MMSI as one of your buddies, the buddy’s
name is displayed in place of the user MMSI.
2. No acknowledgement is required. Press PTT to initiate voice contact on CH16 and then switch to a
working channel.
The call data is stored in the Call Log (see Section 5-2-7).
DSC CALL
CALL LOG
DIST LOG
> LL REQUEST
LL REQUEST
> SAM
RS10
BUDDY #3
SAM
LL REQUEST
CALLING...
SAM
LL REQUEST
> SEND?
channel name
SAM
LL REQUEST
AWAITING ACK
RCV: ALL SHIP
priority
RS10
ESC –> EXIT
