RS86/RS87 VHF
34
E04819 Issue 1.0
Use the VOL ▲ and VOL ▼ keys to select the station you want
to assign to a particular lighting bank. Use the numeric keypad
to enter the bank number (0–63). Press O
K to confirm.
Repeat the above sequence for each station fitted to the RS86/
RS87.
Press O
N/C to exit to the SimNet Management menu.
Note All IS12 instruments are set to “BANK 0” by default. It is not
possible to split IS12 displays into separate banks.
3.3.7.3 Device instance
This option will normally only be used on very large, compli-
cated systems, where there is more than one RS80 system on
the same SimNet bus. For example, on certain vessels it may be
necessary to have more than one VHF radio fitted with different
channel configurations (Fig 3.13).
VHF #1
VHF #2
Fig 3.13 - Multiple RS80 VHFs on the same network
To prevent conflict across the network, these can each be as-
signed a unique device number.
Note “More than one RS80 system” refers to a complete system ra-
dio, including the Rx/Tx transceiver, NOT to a single RS86/RS87
with multiple stations – that is still classed as one radio.
From the SimNet Management menu select “DEVICE IN-
STANCE” and press O
K.
The default device instance number is “000”. Use the numeric
keypad to enter the required device instance number and press
O
K to confirm (see Fig 3.14, p. 35).
The display will show “SELECTED” and the entered device
number for 2 seconds, then exit to the SimNet Management
menu.
