Speed when P1-60 failure occurs
Bus voltage when P1-60 fault
occurs
Effective current when P1-60
fault occurs
Running time when P1-60 fault
occurs
Low 4 bit of encoder single-turn
position value (only for 17 bit
encoder)
High 5 bit encoder single-turn
position value (only for the 17
encoder)
The current total inertia load -
continuous detection
Current load inertia ratio -
continuous detection
Total number of feedback pulses
Received external pulse
frequency
6.2.2 P1 group - Basic control parameters
Control mode selection:
0: Speed control mode
1: Position control mode
2: Torque control mode
3: Speed position switching mode
4: Torque speed switching mode
5: Position torque switching mode
Position command source selection:
0: external pulse command (pt)
1: internal multiple command (pr)
External pulse command input form:
0: Pulse + direction, positive logic
1: Pulse + direction, negative logic
2: Two phase orthogonal pulse (4
times
of frequency), positive logic
3: Two phase orthogonal pulse (4
times
of frequency), negative logic
4: CCW/CW pulse, positive logic
5: CCW/CW pulse, negative logic
Internal position command multiple
execution options:
0: From pr1 to pr16, cycle
1: From pr1 to pr16, not cycle
2: External Di switch
Speed command source:
0: Internal digital given (P3-00
given)
1: Analog quantity 1 given (AI1)
2: Analog quantity 2 given (AI2)
3: Not used
4: Internal multi section speed
command
5: Point running (should make
external JOG DI enable)
Multi section speed selection:
0: Multi section speed automatic
switching, cycle
