Sinee EA100-2R8-2A - Page 55

55
Display mode：Decimal system
Parameter function：Show multi circle value of encoder feedback, range: -32768~+32767
P0-06
Total running time
Initial value
Unit
Communication
Address
0
min
0006H
Control mode：P S T
Data size：32bit
Display mode：Decimal system
Parameter function：Display the total time elapsed after the servo drive is out of the factory.
P0-08
AI1 voltage value
Initial value
Unit
Communication
Address
0
mV
0008H
Control mode：P S T
Data size：16bit
Display mode：Decimal system
Parameter function： Display analog channel 1 acquisition of the actual value of the voltage.
P0-09
AI2 voltage value
Initial value
Unit
Communication
Address
0
mV
0009H
Control mode：P S T
Data size：16bit
Display mode：Decimal system
Parameter function：Display analog channel 2 acquisition of the actual value of the voltage.
P0-10
Encoder sector number (only for 2500ppr
incremental encoder)
Initial value
Unit
Communication
Address
0
-
000AH
Control mode：P S T
Data size：16bit
Display mode：Decimal system
Parameter function：Display the current incremental encoder sector number.
If the motor uses the 2500ppr incremental encoder, the sector number means the UVW combination of the encoder feedback, generally in the
counter clockwise rotation, jump in accordance with : 2- > 6- > 4- > 5- > 1- > 3-.
P0-11
Bus voltage
Initial value
Unit
Communication
Address
0
V
000BH
Control mode：P S T
Data size：16bit
Display mode：Decimal system
Parameter function： Show the actual value of the DC bus voltage in the drive.
P0-12
Effective current value
Initial value
Unit
Communication
Address
0
A
000CH
Control mode：P S T
Data size：16bit
Display mode：Decimal system
Parameter function：Show the effective value of current motor current.
Effective current value
2 2 2
2
()
3
U V W
I I I I  
P0-13
Servo drive current state
Initial value
Unit
Communicatio
n
Address
-
-
000DH
Control mode：P S T
Data size：16bit
Display mode： -
Parameter function：Show the current state of the servo drive.
When selecting the display P0-13, the following figure shows the display of the LED display on the servo drive panel.
