1. Raise the needle to its highest position
by rotating the hand wheel toward you
(counter-clockwise).
2. Open the bobbin access cover by
pulling it down. With your ngers, pull
open the bobbin case latch as shown,
and take out the bobbin case from the
shuttle.
3. Release the latch, and bobbin will drop
out of the case.
1. Hold the bobbin in your right hand with
the thread running clockwise.
2. Insert the bobbin into the case with
about 4” (10 cm) of thread showing
outside the case.
3. Pull the thread through the slit in the
case and then underneath the flat
tension spring. It will click when it is in
place.
4. Keep about 4” (10 cm) of thread
showing outside the case.
REMOVING BOBBIN CASE FROM SHUTTLE
INSERTING BOBBIN INTO BOBBIN CASE
1
3
2
