Singer 6199 - Zigzag Stitching; Adjusting Stitch Width and Length

28
Under side
Top side
If bobbin thread is pulling to the top or you
are experiencing puckering, slightly reduce
the tension with the Thread Tension
Control.
:Presser foot - All Purpose Foot
:Thread tension control - 5
SETTINGS
The light grey boxes indicate all
the possible personal preference
options available to set manual.
Dark grey box indicates the
default value set automatically
when the pattern is selected.
For the Zigzag Pattern the stitch
length is 2 mm and the stitch width
is 5 mm.
ADJUSTING STITCH WIDTH AND LENGTH
STITCH WIDTH
mm 0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0
0
0.3
0.5
0.8
1.0
1.3
1.5
1.8
2.0
2.5
3.0
STITCH LENGTH
ZIGZAG STITCHING
The top thread may appear on the bottom
depending on the thread, fabric, type of
stitch and sewing speed, but the bobbin
thread must never appear on the top of the
fabric.
