Quantum
®
XL-6000
Combination Embroidery
- 30 -
Combination Embroidery is used for arranging design elements to be sewn
within a single hooping. The sewing field size of the hoop area in Combination
Embroidery is 140mm x 240mm (approximately 5.5 x 9.5 inches).
Machine Set Up:
1. Turn machine off.
2. Remove bed from standard machine.
3. Install the embroidery unit.
4. Slide lever (at the front of embroidery unit)
to the right, until it “clicks”.
5. Remove Standard presser foot and shank.
6. Attach the “J” Embroidery foot.
7. Turn machine on.
8. Touch anywhere on the Welcome Screen.
9. Touch OK to position the hoop.
Built-in Embroidery Designs:
The Quantum
®
XL-6000 has 99 built-in floral
designs. These are stored in numbered folders
and displayed on the machine screen.
1. Folder #1 that automatically opens shows a very large Floral Arrangement.
Touch Folder #2, then Folder #3. To continue viewing the built-in
designs, touch the #4 Arrow Pictogram in the upper right area of screen.
2. Continue moving through the design patterns by touching the numbered
folders, up to Folder #17. To select a design from Folders #1 through #10,
touch the small “button”, located within the box of the selected design. To
select a design from Folders #13 through #17, touch the design itself on
screen.
CREATING A DESIGN LAYOUT
1. Touch either Arrow Key (located in upper left/right areas of screen) to
move to Folder #14.
2. Touch the Flower in Row 1, Pattern 1.
3. The design appears on the top of the screen. To enter the design and
access the Editing screen, touch the Pictogram.
4. The Editing functions are now displayed on screen:
Hoop Icon, Position/Zoom/Rotate, Design Sizing, Letter Sizing, and Mirror Image
IMPORTANT: The footprint of
the Quantum
®
XL-6000 with the
Embroidery Unit installed is quite
large. To avoid hoop-positioning
problems it is very important that
Embroidery Sewing is done on a
firm, flat table, large enough to
support the entire unit. The work
area must be free of any
obstructions allowing the hoop to
move freely.
The Embroidery Unit must be at
the same height or even slightly
higher than the portion of the
Quantum
®
XL-6000 freearm bed
located to the left of the needle.
